Solar.

• Max usable input current: 15/15/27A.
• Max short circuit input current: 17/17/34A.
• Start input voltage: 100V.
• Startup voltage: 140V.
• Full power MPPT voltage range: 230-480V.
• DC nominal voltage(V) MPPT tracker: 360V.
• DC voltage range: 100-600V.
• MPPT operating voltage range: 60-480V.
• Maximum PV Array Power: 26000W (7000/7000/12000W)
• Number of MPPT(Strings per MPPT: 3(1/1/2).

Battery.

• Type: Lead-acid /Lithium.
• Max charge/discharge current: 20A.
• Nominal voltage: 48V.
• Voltage range: 40-60V.

Grid.

• Nominal output current: 50A.
• Max output current: 55A.
• Rated voltage: 240V.
• Operating voltage range: 180-270V.
• Nominal power output: 12000W.
• Max. apparent AC power: 13200VA.
• Operating frequency: 50/60Hz.
• Operating frequency range: 45-55/55-65Hz.
• Phase shi (cos ) 0.99@full load.
• Reactive power adjust range: -0.8~+0.8.
• THDI: <3%.

Ups.

• Nominal output current: 50A.
• Nominal output voltage: 240V.
• Rated output power: 12000VA.
• Operating frequency: 50/60Hz.
• THDv: <3%.
• Switch time: <20ms.

Efficiency

• EU Efficiency: 98%.
• Max.Efficiency@PV to the grid: 97.50%.
• Max. Efficiency@ battery to the grid: 95%.
• MPPT Efficiency: 99.90%.

Protection.

• Integrated disconnect: DC switch.
• Reverse polarity protection: YES.
• DC switch rating for each MPPT: YES.
• Output over-voltage protection: YES.
• Output over current protection: YES.
• Ground fault monitoring: YES.
• Grid monitoring: YES.
• Pole sensitive leakage current monitoring: YES.
• AFCI: OPT.
• RSD: OPT.

General.

• Dimensions: 650*440*220mm.
• Weight: 38kg.
• Degree of protection: IP65.
• Cooling concept: FAN.
• Topology: Transformer-less.
• Relative humidity: 0~100%.
• Altitude: <2000m.
• Noise emission: <50dB.
• Internal consumption: <15W.
• Communication interface: 485/Wi-Fi/CAN.
• Standard Warranty: 5 years.
• Display Touch colour screen.
